Wet cat food bag sorting machine: 1. Automatic sorting and output; 2. Removal of stacked bags; 3. Detection of bag orientation bag flipping; 4. Adjustment of bag orientation; 5. Counting and collecting bags; 6. Packing bags into boxes.
Sorting machine + customized rejector + counting collecting machine + premade bag packing machine. It is suit for the following products: snack sachets, rice bar sachets, 3/4-side seal sachets, etc.
VFFS double-line jelly bag packing machine can automatically complete the bag-making process, including feeding, metering and filling, bag forming, date printing, sealing, shape cutting, and finished product output.
FBV-50YD irregular shaped bag packing machine can automatically complete process such as feeding, bag forming, metering, date printing, filling, sealing, die-cutting, and counting.
VFFS jelly triangle sachet packing machine features functions such as forming, filling, sealing, die-cutting, date printing, in-can mixing, and heating. It offers high packaging efficiency and excellent bag sealing.
4-head scale packaging machine has been exported to Côte d'Ivoire, Africa, and can produce corner-insertion bags. It can package 2kg of powders such as: washing powder, milk powder, and wheat flour.
4-side seal sachet sorting + counting + conveying. Sorting machine can separate and output individual bags from large stacks. Optionally connects to bagging or boxing machine.
Stick bag pack + sort + count + carton machine. Sorting machine handles conveying, spreading, and rejection, sorting and outputting products one by one.
Stick bag sorting + counting + output conveyor with table (same face and orientation). It is suit for sorting stick bags, 4-side seal sachets, pillow bags, etc.
General instruction of sachet/bag sorting counting machine with output conveyor
1. Automatic stick bag/sachet sorting machine working principle: After the irregularly piled stick bags are poured into the storage hopper, the hopper conveyor belt moves, transporting the materials to low-speed rollers. Depending on the bag condition, the equipment uses low, medium, and high-speed rollers to sequentially feed the stick bags out of the bag sorting machine.
2. Counting machine: It can be used for product conveying and counting. Once the set quantity is reached, output door open and dropping bags down.
3. Output conveyor with table: Horizontal bowl type conveyor can be connected with vertical packing machines box packaging depending on requirements. and it's easy for manual taking bags by hand
Other discription
1. Lifting conveyor: Used to convey large stacks of bags upwards in small batches. Prevents excessive product overlap and facilitates subsequent handing.
2. Steering unit: Used to transport products laterally to the next step, facilitating the removal of stacked stick sachets.
3. Guidance block: Used for rejecting stacked sachets and aligning conveyed products for neatness. Customization is available based on bag shape and weight.
Guidance block
Steering unit
Stick sachet lifting conveyor
Automatic sorting counting machines are suitable for packaging products in industries such as food and pharmaceuticals. Sachet sorting machines can handle strip bags of different shapes and styles, such as coffee powder strip sachets, protein powder strip sachets, mouthwash stick sachets, and milk powder strip sachets.
| Model | FBV-WX-02 sachet sorting counting machine with conveyor |
| Size of machine | According with products (standard size: L*W*H: 5600*970*1800mm) |
| Sorting range | Width of bag: 10-150mm, Length of bag: 30-200mm |
| Sorting speed | 100-250 bags/minute |
| Weight of machine | 1200 kgs |
| Power | 8kw, 1 phase 220V, 50-60Hz, note: voltage is customized |
As a professional packaging machinery manufacturer, Shanghai FU-BO Packaging Machinery Co., Ltd.
has well-equipped testing facilities, strong technical force, provide customers with a variety of packaging machinery solutions.
Shanghai FU-BO Packaging Machinery Co., Ltd. is a manufacturer of automatic packaging machinery with well-equipped testing facilities and strong technical force.
