Wet Cat Food Bag Sorting Machine: 1. Automatic sorting and output; 2. Removal of stacked bags; 3. Bag orientation detection and bag flipping; 4. Bag orientation adjustment; 5. Bag counting and collection; 6. Bag packing into cartons.
Sorting machine + customized rejector + counting collecting machine + premade bag packing machine. It is suit for the following products: snack sachets, rice bar sachets, 3/4-side seal sachets, etc.
Vertical double-line jelly sachet packaging machine completes feeding, dosing, bag forming, filling, sealing and cutting automatically. Supports single or dual-lane packaging with independent operation.
FBV-50YD irregular shaped bag packing machine forms bottle-shaped pouches through custom die cutters. It is suitable for packaging energy gel, liquid coffee, shampoo, syrup, sauces and various liquid cosmetics.
VFFS triangular jelly sachet package machine integrates forming, filling, sealing, die cutting, date coding, internal mixing and heating processes. It achieves high packaging efficiency and reliable sealing quality.
Automatic 4-head weigher packaging machine has been successfully exported to Côte d’Ivoire, Africa. It features gusseted bag making function and realizes automatic quantitative packaging for 2kg washing powder.
Bag Sorting + Belt Conveyor + Counting & Collecting + Case Packing. It integrates the functions of feeding, sorting, counting, box picking, box opening, product pushing, flap folding, case sealing and finished product discharge.
Automatic 4-side seal pouch sorting, counting & collecting and cartoning line. It is suitable for sorting 3-side seal sachets, 4-side seal pouches, snack stick bags, pillow bags and other similar pouch packages.
Stick Sachet Sorting, Counting, Conveying & Cartoning System. It automatically separates stick sachets from the hopper one by one, then conveys and packs the quantified products into cartons.
Sachet Sorting Counting & Case Packing Production Line Operation Instructions：
1. Sachet sorting machine is seamlessly linked with counting machine and cartoning machine to form a fully automated integrated sorting workflow. It arranges randomly piled sachets and pouch bags in disorderly stacks into neat single-row alignment, then feeds them out one by one in standardized order.
2. Main structural components of the bag sorting unit include material storage hopper, photoelectric sensing system, lifting conveying mechanism, roller conveyor, crosswise conveyor, metering counting module and human-machine touch control panel etc.
3. Counting & gathering machine can be docked with upstream sorters and downstream carton packers stably. It delivers high-precision quantity counting, tidy material arrangement and smooth follow-up packing procedures.
4. Automatic cartoning case packer realizes full-process unmanned operation including automatic carton feeding, carton opening, material box loading, material pushing, carton sealing and finished product discharging. It adopts compact and optimized packaging layout, featuring easy operation and flexible parameter adjustment.
Suction cup for taking and opening the box
Counting and collecting bags
Bag sorting chute
Automatic sorting, counting and case packing machine is suitable for sorting and conveying various packaged products, including hot pot seasoning pouches, 3-side sealed peanut sauce bags, 4-side sealed cat food bags, pillow-style milk powder bags, three-side sealed medical powder sachets and other similar bagged goods.
Cartoning machine is applicable to diverse product packaging scenarios, covering biscuits, soaps, coffee sachets, sugar sticks and other daily necessities and food items. Custom carton dimensions and sealing styles are available to match different product specifications and packaging requirements.
| Machine name | bag/sachet sorter counter case packer packaging line |
| Product size | According to the actual situation |
| Machine materials | 304 stainless steel |
| Sorting bag size | 10-200 mm |
| Packing capacity | 50-3000 bags/min |
| Power supply | 1 ph-220v-50hz or 3 ph-380v-50hz |
| Applicable bag shapes | 3/4-side seal bags, stick bags, shape bags, etc. |
| Machine function | bag feeding, rejection, sorting, counting, opening box, cartoning, sealing, etc. |
