Wet Cat Food Bag Sorting Machine: 1. Automatic sorting and output; 2. Removal of stacked bags; 3. Bag orientation detection and bag flipping; 4. Bag orientation adjustment; 5. Bag counting and collection; 6. Bag packing into cartons.
Sorting machine + customized rejector + counting collecting machine + premade bag packing machine. It is suit for the following products: snack sachets, rice bar sachets, 3/4-side seal sachets, etc.
VFFS double-line jelly bag packing machine can automatically complete the bag-making process, including feeding, metering and filling, bag forming, date printing, sealing, shape cutting, and finished product output.
FBV-50YD irregular shaped bag packing machine can automatically complete process such as feeding, bag forming, metering, date printing, filling, sealing, die-cutting, and counting.
VFFS jelly triangle sachet packing machine features functions such as forming, filling, sealing, die-cutting, date printing, in-can mixing, and heating. It offers high packaging efficiency and excellent bag sealing.
Automatic 4-head weigher packaging machine has been successfully exported to Côte d’Ivoire, Africa. It features gusseted bag making function and realizes automatic quantitative packaging for 2kg washing powder.
Premade bag multi-head granule packing machine can automatically complete bag picking, bag opening, metering, filling, sealing and output. It is suit for packing biscuits, walnuts, cat food, popcorn, etc.
Pet food zipper doypack bag filling machines select feeding and metering devices according to different products: Z-type elevator, multi heads scale. It is suit for packing dried fruits, chocolates, puffy food, etc.
Premade bag packing machines can package granular products such as candies. Bag types can be customized according to customer requirements: stand-up pouches, irregularly shaped bags, 4-side seal bags, etc.
Premade bag granular packaging machines can be equipped with components including multi-head weighers, Z-type elevators, support platforms, bag storage units, bag picking mechanisms, bag opening devices, filling units, and bag sealing systems. The entire system can be controlled via a touchscreen, which offers clear display and enables easy viewing of packaging parameters.
1. Multi-head weighers: Customizable with 8, 10, 14, or 20 heads. Made of food-grade stainless steel, they ensure hygiene, safety, and accurate measurement.
2. Support platform: Constructed of stainless steel, it facilitates easy inspection of the multi-head weigher’s proper operation and ensures the operational stability of the machine and weighing device.
3. Z-type elevator: Made of food-grade stainless steel and equipped with a transparent glass cover for easy viewing, it is used for conveying granular products while ensuring product integrity.
Z-type elevator
Multi-head scale
Heat sealing
Multi-head weigher packaging machine is widely suitable for packaging large granular products of various shapes, including spherical, and irregularly shaped granular products. Examples include pet food (such as cat/dog food), snacks (such as biscuits, potato chips, candies, and walnuts), and other granular items.
Premade pouch packaging machine is compatible with multiple pouch types: stand-up pouches, corner pouches, 3-side sealed pouches, 4-side sealed pouches, zipper pouches, bottom self-standing pouches, and special-shaped pouches.
| Model | FBG-200-S | FBG-230-S | FBG-300-S |
| Pouch Type |
all kinds of premade bags or pouches, flat bag, 3-side sealing bag, 4-side sealing bag, zipper bag, stand-up bag, etc. |
||
| Pouch Material |
Laminated film, PP, PE, Foil, Paper, etc. |
||
| Pouch Size | W:80-210mm L:150-300mm | W:80-230mm L:150-300mm | W:150-300mm L:150-300mm |
| Packing weight |
5-1500g |
||
| Packing speed |
20-60 bags/min (depends on the packing material and filling weight) |
||
| Packing Accuracy | ≤±1% | ||
| Power |
3.5KW-4.5KW, AC380V, 50Hz |
||
| Air Consumption |
0.3 m³/min |
||
|
Overall Dimensions (mm) |
Min. 4200*2000*3700 Max.4650*2350*3750 |
||
